Laser Displacement Sensor

Ultra High-Accuracy

No. 1 linearity,+/- .015%FS
Developed image sensor ATMOS
Ethernet connection
Web Server

Middle Range

B-I-C repeat accuracy 0.25 micron
F-in-Class sampling: 133.3 μs
up to 1200 mm
OLED display

Compact

Smallest in class
CC-Link fieldbus
Built-in amplifier & 4-digit display
Performance like high-end models

Small

Half-palm size.
Specular reflection available
Control units for Mitsubishi PLC

Displacement Sensor Handbook

Optex Brochure

BGS Distance Setting Sensor

Z4B Series IO-Link

High power and small spot LED light source
Enhanced ambient illuminance resistance

Compact TOF with Display

Models with IO-Link, Analog Output, and 3 Control Outputs Available
High Performance with Class 1 Laser
High Accuracy Operation with Low Hysteresis
cUL / CE
Sensing Distance 2.5 M

Compact Long Range

Max. sensing distance of 4.5 m (*With white paper (90%)
Compact design TOF Sensor
Capable of stable detection even over long distances
Sensing Distance 4.5M

Long Sensing Distance

Immune to object color and angle
Sensing Distance :
3.0 M Diffuse Reflective
20.0 M Retro Reflective

Background Suppression Sensors

Optex FA Time of Flight Sensors

High-accuracy Laser Sensors

Minimum detectable height difference = 0.08 mm (BGS-HL05 / HDL05 )
Built-in controller and 4-digit display
Stable detection regardless object color

Standard-sized Sensors

Highly accurate height difference detection due to low hysteresis
2 sensing ranges with laser models and 3 sensing ranges with LED models available
Fast response of 250μs on laser models and 500μs with LED models
Sensing Distance 4.5M
cRUus

Small BGS Sensors

For locations with small mounting space
For accurate detection of small workpieces

M18 Cylindrical

Easy to install and maintain M18 structure
Metal and plastic housing models
300mm detection distance
Fast Response time of 1 ms
cRUus

Stainless-steel Housing

Excellent water resistance/ oil resistance!
Equipped with a distance adjustment to enable distance setting
Employs a low deterioration 4 element red LED for the Light source
Degree of protection: IP69K (cable type), Equivalent to IP69g (connector type)

Universal Voltage LED BGS

Dual lens achieves long range detection
Maximum sensing distance of 1 m
Capable of stable detection even over long distances
cRUus
IP67

Photoelectric Sensor Handbook

Optex Brochure

CDX Application Videos

CD2H/CD22 Application Videos

BGS Distance Setting Sensors
